NIS/NISF/NISO Series - End Suction Centrifugal Pumps
Technical Data
• Flow rate: 3m³/h ~ 1200m³/h
• Head: 4m ~ 160m
• Temp: -15°C ~ +110°C
• Material: Stainless steel/Cast Iron
• Max. working pressure: 16 bar
• Max. Inlet pressure: 6 bar
• Max. Power: 200kW
• Inlet diameter: DN50~DN300
• Outlet diameter: DN32~DN250
Download
Product Introduction
NIS/NISF/NISO series are non-self-priming single-stage horizontal end-suction centrifugal pumps with axial inlets and radial outlets. With the back-pull structure, maintenance does not require dismantling the pump body and pipeline.
Advantages
• Stable operation and structure.
• Convenient maintenance.
• Low noise
• Standard wear-resistant mechanical seal.
• The sizes of the TEFC motor comply with IEC standards.
• The bearing cradle prevents radical vibration.
• NISO Pump dimension conforms to ISO2858 standard
Applications
• Water treatment systems.
• HVAC systems.
• District heating.
• Industrial cooling systems.
• Firefighting systems.
• Industrial boosting systems.
